Millet Processing Plants
Millet Processing Plants

Millet Processing Plants

Finished product:Processed pearl millet, kode millet, finger millet, proso millet, and foxtail millet

Production capacity:10-1000Ton/day as required

Core equipment:Pre-Cleaner, Destoner, Dehuller, Separator, Milling Machine, Iron Roller Polishing Machine and Grader, Optical Sorter, Packing Scale.

VIDEO

PROCESS OVERVIEW

  Millet is an essential grain in people's daily life with its highly nutritious than age old cereals. It is difficult for us to get high qyality millet just by hand. Here comes the requirement for developing right automatic and mechanical millet processing unit for all the millets that are processed and consumed to meet different millets processing such as proso millet, foxtail millet, little millet, barnyard millet,kodo millet,pearl millet, finger millet, brown top millet and jowar.

  Our millet processing technology covers the full range of millet pre-cleaning, hulling, polishing, optical sorting to bagging.

  Instaking and cleaning: remove impurities such as stems and leaves, soil lumps, stones and moldy particles in raw materials through multistage cleaning process to ensure the purity of raw materials. All the cleaning equipment is treated by suction to make the equipment in negative pressure state, so as to ensure that the dust does not overflow and the environmental sanitation of the workshop.

  Husking separation: husker and separator remove the husk from the outhulls of the material and separate from the kernel to obtain pure kernel.

  Polishing and grading: the pure millet kernel is polished by a polishing machine to remove the impurities on the surface of millet kernel, increase the surface gloss and further increase the purity of millet kernel.

  The following overview shows all machines which are used for the processing of millet. You will find information on various WIN TONE machines.


Raw Millet
Cleaning


Hulling

Milling

Processing

Millet
Cleaning
Because the uneven quality of raw paddy, the purpose of cleaning is to remove all kinds of impurities in the paddy through various cleaning equipment, making it meet the quality requirement of further processing.
Sifting:
Removing large, small and light impurities in millet according to their different size and shape from the paddy.
Gravity grading:
Separating impurities base on their differences in density, friction coefficient, suspended speed and other physical characteristics with the paddy through the gravity grading equipment.
Magnetic separation:
By putting the paddy through the magnetic field, the ferromagnetic impurities are separated hence avoid damaging to the processing facilities.
Cleaning:
To ensure the quality of millet and protecting the processing equipment, before entering into the milling process from temporary storage, the pre-cleaned millet needs further cleaning. This process utilizes a variety of means, such as screening, aspiration separation, magnetic separation, stone removal, Millet scouring, optical sorting and so on.
Features:
—Low power consumption;
—Good cleaning effect;
—Easy operation, low maintenance.
Hulling & Separating
INTRODUCE:
The cleaned paddy enters into the hulling process, and the husks are removed by the hulling equipment to obtain pure brown millet.
Features:
Complete separation of millet and husks;
Low broken rate.
Millet Milling
INTRODUCE:
Millet milling is the process of to separate and remove the husk and bran to obtain the edible portion of paddy. It is the process which transforms paddy into edible millet. The process has to be accomplished with care to prevent excessive breakage and improve the quality of millets.
To reduce breakage and the grain temperature during the whitening process, the paddy is normally passed through several whitening and polishing machines connected in series. The arrangement of machines to process the millet is dependent on the physical characteristics of paddy. Proper sequencing and arrangement of the machines will help lower the broken rate.
According to the quality requirement of end product, we provide reasonable configuration and arrangement of machines in the process design ensuring the quality standard of finished product with lower energy consumption.
Features:
High yield with less broken millet;


FEATURE

  • Advanced and Automatic Technology

    Adopting new process of shelling first and then light grinding solves the problems of hard grinding with shell, uneven grinding in traditional process.

  • Good Quality Core Equipment

    Equipped with fine cleaning and shelling equipment, new grinding machine and independent development of millet efficient grading equipment.

  • Convenient Operation & Maintenance

    Realizing automatic and continuous operation from raw grain cleaning, stone removal, multistage shelling, grinding and polishing.

  • Lower Energy Consumption

    Application of new energy-saving equipment reduces energy consumption of the whole machine

MAIN MACHINES

  • Millet Processing Plants
  • Millet Processing Plants
  • Millet Processing Plants

FINISHED PRODUCTS

Millet Processing Plants FINISHED PRODUCTS

TECHNICAL INDEX

Type Finished product requirements Equipment configuration
Oily millet  Pure color ,Bran free Hulling Hulling, Peeling,Polishing
Ordinary millet Pure color ,Bran free Hulling Peeling,Polishing
